RED ROOSTER pneumatic chain hoists
RED ROOSTER air chain hoists are manufactured by TOKU Japan. Japanese production stands for high quality in engineering, design and performance as only the best methods and materials are used for the production of the RED ROOSTER air hoists.
We are able to deliver all standard hoists ranging from 125kg up to 50 tonne from stock, making sure you can have the hoist you need available with very short delivery times.
• 100% duty rating
• Variable speed regulation, precise positioning of the load, soft start and stop, no shock movements
• Compact design, low headroom
• Silenced planetary gear durable lubricated
• Safety factor 5
• M4 group of mechanism
• End Stop system automatic at highest and lowest position of the chain
• Cord control or pendant control with emergency stop
• Temperature range: -20ºC till 70ºC
• Standard explosion protected (ATEX)
• In house design for custom requests
Build to withstand extreme conditions
The RED ROOSTER air chain hoists and trolleys are made to work under extreme conditions and are therefore very suitable for intensive use in industrial environments. Our hoists are in use in a wide variety of industrial and marine environments like On- and Offshore (oil) industry, shipyards, assembly lines, power plants, refineries, foundries, paper industry, paint shops, tank cleaning, (petro) chemical industry, galvanizing industry, food industry, automotive industry, construction and many other industries. RED ROOSTER air hoists can work in humid environment, outside in the field, hot, cold and aggressive atmospheres.
Basically, everywhere where the combination of high performance, reliability and safety is required.
RED ROOSTER air hoists are standard explosion protected
Contrary to electric hoists, RED ROOSTER air powered hoists do not produce sparks and are therefore suitable to operate in hazardous areas. Depending on the level of protection needed RED ROOSTER hoists can be adapted with additional protection to operate in zones with a higher explosion risk.
All RED ROOSTER pneumatic hoists and trolleys from 250kg to 100 tonne are standard suitable for use in areas certified as:
II 3 GD c IIA T4
With extra spark protection our hoists can be used in areas certified as:
II 2 GD c IIB T4
Further protection allows the hoists to operate in areas certified as:
II 2 GD c IIC T4
(not suitable for TCR mini, TMM or TCS range)
Download our full RED ROOSTER air hoist catalogue:
For more information about our hoists, the broad range of options or for questions regarding hoists required to operate in higher hazardous areas, please contact our sales department.
